Description AG-3150E Aquaguard – Pan Sensors – E:Mail: [email protected] to confirm availability or for volume discounts The AquaGuard AG-3150E’s primary pan sensor is mounted directly in the auxiliary drain of the primary drain pan. The bonus secondary sensor can be installed either vertically or horizontally and features a water detection LED light. For a vertical application, the bonus secondary sensor can be mounted on the side of the unit. For a horizontal application, the bonus secondary sensor can be installed directly in the metal or plastic secondary drain pan, which allows both sensors to continuously monitor any condensate overflow in both the primary and secondary drain pans. If any condensate overflow is detected in either drain pan, the sensor(s) will automatically shut off the system and activate an alarm in as little as 1/16″ of water. Patent pending smart sensor technology with time delay Redesigned probe sensor for increased reliability Bonus secondary sensor with water detection LED light 6′ of both probe and sensor wire 5 Amp, 24 Volt AC solid state sensor with water detection LED light Switch can be Normally Open or Normally Closed Normally open 4th wire for optional external alarm, digital controller or energy management dystems Compact waterproof design US patents and patents pending UL 508 Approved Attributes Approvals UL Listed; UL Recognized Brand Aquaguard® Color Black, Clear Composition Plastic Connection Size 3/4″ Cord Length 6′ Country of Origin CHN Cubic Measurement 0.068 Cycle/Hertz 60 Hz Dimensional Weight 1 EAN 0021449961240 For Use With In both primary and secondary drain pans Maximum Amps Running 5 Mounting Type Secondary Mounts Adhesive Tape Phase Single Plenum Rated NO Prop 65 NO Size 2.6″ x 1.4″ x 1″ Switch Type Electronic Type Pan Sensor UOM EA UPC 021449961240 Voltage 24 VAC Wire Gauge 18 AWG
