Description AG-1200 Aquaguard – Magnetic Float Switch – E:Mail: [email protected] to confirm availability or for volume discounts The AquaGuard AG-1200 offers all of the same industry leading features of the AquaGuard 1100 magnetic float switch plus an innovatively designed two-piece clamp, which allows it to be mounted to either the side of a metal secondary drain pan or the rolled edge of a plastic secondary drain pan. The AquaGuard AG-1200 has a trigger sensitivity of less than 1/2″ of condensate overflow. When the highly buoyant float activates the precision magnetic switch, the AquaGuard AG-1200 will automatically shut off the HVAC/R system and activate any connected alarm. The AquaGuard AG-1200 has been redesigned with a higher 24VAC, 5 amp capacity to protect against power fluctuations and features a smaller, more compact footprint. Incredibly easy to install in ten seconds or less, the AquaGuard AG-1200 can be mounted to a metal or plastic secondary drain pan by simply tightening three thumbscrews without intruding into the pan. The AquaGuard AG-1200 also has an easy lift float pin test knob to ensure sensor reliability. Industry Leading Magnetic Float Switch for Metal or Plastic Secondary Drain Pans High Capacity 5 Amp, 24Volt AC Sensor Easy, Drill-Free Installation Residential and Commercial Applications Lift Float Pin Test Knob Protective Housing Keeps Out Insulation, Pests, and Debris Normally Open 3rd Wire for Optional External Alarm, Digital Controller, or Energy Management System US Patents and Patents Pending UL 508 Approved Attributes Approvals UL Listed; UL Recognized Brand Aquaguard® Color Beige Composition Plastic Connection Size Clips to drain pan Cord Length 6′ Country of Origin CHN Cubic Measurement 0.0802 Cycle/Hertz 60 Hz Dimensional Weight 1 EAN 0021449961066 For Use With Metal/plastic secondary drain pans Maximum Amps Running 5 Mounting Type Secondary Mounts Thumbscrew Phase Single Plenum Rated NO Prop 65 NO Size 4″ x 2.9″ x 3″ Switch Type Megnetic Float Type Magnetic float switch UOM EA UPC 021449961066 Voltage 24 VAC Wire Gauge 18 AWG
